PULSER3-ECAT
PULSER3-ECAT
6 AXIS SIMULTANEOUS CNC CONTROLLER
PULSER3-ECAT is a domestic CNC controller designed for use in CNC machine applications. It uses high-performance EtherCAT network protocol and supports 6-axis simultaneous motion control.
Thanks to its powerful processor and hardware, it provides fast and uninterrupted processing power. Additionally, it is designed to increase user productivity with its user-friendly interface and easy programming features.
It can be used in many different industrial applications. For example, it is ideal for CNC machining centers, robotic systems, laser cutting, plasma cutting machines, and other industrial machines.
PULSER3-ECAT has been developed as part of a project aimed at increasing domestic production capabilities in Turkey's industrial automation field. Therefore, it is designed to meet the needs of customers looking for domestic CNC controllers.
| PULSER3-ECAT | |
| Controlled Axes | 6 |
| Axis Control Method | EtherCAT |
| Comm. Speed | 100 Mbps |
| Control Period | 1ms |
| Feedback | Yes |
| Absolute Feedback | Yes |
| Digital Inputs | Built-in 20 Isolated Digital Inputs (PNP/NPN) |
| Digital Outputs | Built-in 16 Isolated Digital Outputs (NPN, 50mA each) |
| Analog Input | No |
| Analog Output | +/- 10 V Bipolar (Spindle Speed Command) |
| Enkoder Input | 5V Line Receiver (Spindle Feedback) |
| Ethernet | 100Base-TX/10Base-T Ethernet (Protocol MODBUS TCP) |
| CAN-BUS | 1 Mbit Isolated (For Expansion I/O Modules) |
| RS-485 | 19200 Kbps Isolated (MP or General Purpose Usage) |
| RTCP | Yes (Licence Required) |
| Memory | Micro SD Card (32 Gbyte) |
